Description
OR Table with Modular Design to Suit Your Needs
The Berchtold OPERON® Modular OR Table comes in three varying bases, the D 850, the D 820, and the D 760. Each base offers varying height adjustment and positioning surfaces.
There are a wide variety of accessories available for the Berchtold OPERON® to accomodate multiple surgical modalities.
D 850 Features
- Height Adjustment: 22 - 46 in (580 - 1180 mm)
- Maximum Patient Weight: 1250 lbs (567 kg)
- Longitudinal Slide
- Ideal for seated or standing surgical procedures
- Maximum flexibility for imaging
- Foot pump safety system and backup hand pendant
D 820 Features
- Height Adjustment: 25 - 42 in (635 - 1075 mm)
- Maximum Patient Weight: 1000 lbs (454 kg)
- Longitudinal Slide
- Ideal for multiple inpatient and outpatient surgeries
- Foot pump safety system and emergency hand pendant under table
- Maximum flexibility for imaging
D 760 Features
- Height Adjustment: 25 - 42 in (635 - 1075 mm)
- Maximum Patient Weight: 1000 lbs(454 kg)
- No Longitudinal Slide
- Ideal for gynocological procedures
- Foot pump safety system and emergency hand pendant under table
Specifications
| Technical Data | D 850 | D 820 | D 760 |
|---|---|---|---|
| Max. patient weight | 567 kg for normal orientation 227 kg for reverse orientation |
454 kg for normal orientation 227 kg for reverse orientation |
|
| Height adjustment (without pad) | 575–1180 mm | 635–1075 mm | |
| Longitudinal slide | 430 mm1, 330 mm2 | - | |
| Trendelenburg/reverse Trendelenburg | 30°/31° | ||
| Tilt left/right | +20°/–20° | ||
| Back plate up/down | +90°/–45° | ||
| Leg plate up/down | +30°/–105° | ||
| Split leg plates up/down | +30°/–90° | ||
| Head rest up/down | +45°/–90° | ||
| Kidney elevator (optional) | Lift to 75 mm | ||
| "Flex" (Auto position) | 225° | ||
| Table length3 | 2124 mm | ||
| Tabletop width (inc. side rails) | 534 mm (587 mm) | ||
| Image width | 465 mm | ||
| Manual backup system | integrated | ||
| Collision protection with all powered tabletop functions | integrated | ||
| X-ray cassette channel | continuous | ||
| Serial interface4 | integrated | ||
| Battery capacity | 5-8 working days | ||
| Segments of OR tabletop3 | up to 8 | ||
| Tabletop material3 | Carbon fibre/phenol | ||
| Base material3 | Reinforced fibre plastics/ABS polymer, stainless steel | ||
- Measurements according to EN 60 601-2-46
- Values are subject to a general industry tolerance of +/- 3%
- 1 with kidney elevator
- 2 without kidney elevato
- 3 depends on configuration
- 4 Serial interface allows communication options such as computer-based service support and external control capabilities by voice control for integrated operating rooms.
