DRE True ECG Plus Six-channel EKG Machine
0 items are in your cart. View cart now.
Need Advice? Ask Our Experts!
(800) 462-8195
Description
An excellent cost-effective EKG machine for hospitals, family practices and emergency responders.
Features
- Portable, lightweight design - Convenient for mobile use and offices with limited space
- Easy data input and operation - Alphanumeric keyboard and one-touch operation
- Power supply - Built-in rechargeable battery, AC/DC power supply
- Pacemaker detection - Meets the requirements of ANSI/AAMI EC11
- EKG / ECG Interpretation - Automatic measurement and interpretation for adults and pediatrics
- Periodic recording - Two-step exercise test with periodic recording
- Heart rate variability (HRV) analysis
- Recording - Internal thermal printer and external printer
- Memory and data transmission - SD card and card reader, and flash drive (not included)
- Data transmission to PC via Ethernet or RS232 port
Options
- Internal storage upgrade to 200 ECGs
- PC-based data managementsoftware (Smart ECG Viewer)
- XML format export
- SD card and card reader, flash disk
- Rolling stand and carrying bag
Specifications
General
- Input circuit: Defibrillation protection
- Lead: Standard 12 leads
- Acquisition mode: 12-channel simultaneous (10-24s adjustable)
- A/D converter: 24 bits
- Sampling rate: 1000Hz/channel, 10,000Hz for pacemaker detection
- Input voltage range: ±5mVp-p
- Time constant: >3.2s
- Frequency response: 0.05Hz-150Hz
- Calibration voltage: 1mV±2%
- Sensitivity: 2.5, 5, 10, 20, 10/5, AGC (mm/mV)
- Input impedance: >50M Ω
- Input circuit current: < 10nA
- Noise level: < 12.5 μ Vp-p
- Patient leakage current: < 10 μ Vp-p (220V-240V)
- Patient auxiliary current: < 0.1 μ A (DC)
- Filters: EMG filter 25Hz/35Hz/45Hz/OFF, Anti-baseline drift 0.05/0.15/0.25/0.5Hz, Low-pass filter 75Hz/100Hz/150Hz, AC filter 50Hz/60Hz
- CMRR: >115 dB
- Recording modes: Auto/manual/rhythm
- Rhythm lead: Single channel or three channels selectable
- Power supply: AC (100-240V@50/60Hz) 12V Vehicle-Carried Inverter Li-ion Battery
- Battery: Built-in rechargeable Li-ion battery 2200mAh@14.8V for 6 hours general use or 280 copies EKG / ECGs continuous printing
- Recorder: Thermal printer
- Recording paper: 110mm × 140mm × 144P (Z-fold)
- Recording speed: 5mm/s,6.25mm/s,10mm/s (±3%) 12.5mm/s,25mm/s,50mm/s (±3%)
- Weight: Approximately 3 kg (including battery and paper)
- Dimensions: 322m × 310mm × 101mm
- Display: 5.7" TFT color LCD, 640x480 dots
- External input: 100K Ω, sensitivity 10mm/V±5
- External output: 100 Ω, sensitivity 1V/mV±5%
- Communication interfaces: Ethernet or RS232
