EspañolRespironics Lifecare PLV-102 Ventilator - Refurbished
Respironics Lifecare PLV-102 Ventilator - Refurbished
Este producto es muy dificil para encontrar o ya no está disponible de DRE, por favor vea la lista de productos relacionados abajo o pedir su experto de equipos para informacion sobre un producto similar disponible.
0 Los artículos están en tu carrito. Mirar Carrito ya.
¿Necesita asesoramiento sobre los equipos? ¡Pregunte a Nuestros Expertos!
(502) 244-6333
Descripción
This lightweight ventilator is well suited for transport and portable applications. Controlled by a microprocessor, the piston-driven PLV-102 delivers volume ventilation in a range of settings. With features that include three power source options, it is ideal for use in the sub-acute care, nursing home, or home settings.
Especificaciones
Physical Weight & Dimensions
- Height: 9 inches (22.9 cm)
- Width: 12.25 inches (31.1 cm)
- Depth: 12.25 (31.1 cm)
- Weight: 28.9 lbs (13.1 kg)
Power
- 120 VAC 50/60 Hz
- 12 VDC External Battery
- 12 VDC Internal Battery
Front Panel Controls
- Mode Selection: Control, Control + Sigh, Assist/Control, Assist/Control + Sigh, SIMV
- Tidal Volume: 0.05 to 0.20 ± 0.02 liters; 0.20 to 3.00 liters ± 10%
- Sign Volume: 150% of Set Tidal Volume
- Sign Frequency: 1 Sign Breath every 100 Tidal
- Breath Rate: 2 to 35 BPM ± 0.5; 36 to 40 BPM ± 2
- Inspiratory Flow Rate (Peak flow rate during inspiratory time): 10 to 120 LPM
- Battery Test Switch: Test Internal/External Battery
- Main Power Switch: On/Off, Recharge
- DC Circuit Breaker: Push/Pull Actuation
- AC Circuit Breaker: Push/Pull Actuation
- Airway Pressure Limit: 5 to 100 cm H2O ± 5
- Sensitivity: +18 cm H2O ± 1 to at least -6 cm H2O
- Low Pressure Alarm: 2 to 40 cm H2O ± 2; 41 to 50 cm H2O ± 5
- Manual Sigh: Push to Activate One Breath
- Oxygen Percent (See Operators Manual for Oxygen Delivery Limitations): 21% to 90% ± 6%
- Oxygen Sensor - SIMV Operation (See Operators Manual for Oxygen Delivery Limitations): 21% to 90% ± 10%
- 30 Second Alarm Silence: Push to Activate
Front Panel Visual Indicators
- Manual Sigh: Yellow Indicator Light
- Tidal Volume: Digital Display
- Rate: Patient Breaths Per Minute - Digital Display
- I:E Ratio: Digital Display
- Inspiratory Flow Rate: Digital Display
- Increase Inspiratory Flow: Red Indicator Light
- 120 VAC Power Source: Green Indicator Light
- Patient Airway Pressure: -10 to 100 cm H2O ± 5 (Pressure waveform is sinusoidal)
- Internal DC Power Source: Amber Indicator Light
- External DC Power Source: Yellow Indicator Light
- Assisted/Spontaneous: Green Indicator Light
- 15-Second Delay (Low Pressure Alarm): Green Indicator Light
- Oxygen Percent: 50% and Greater Marked Red
- 30-Second Alarm Silence: Yellow Indicator Light/Push Button
- Alarm Code Display (in Flow Window): Digital Display
Alarms
- Low Pressure: Visual/Continuous Audible
- High Pressure: Intermittent Audible
- Apnea: Visual/Continuous Audible
- Inverse I:E Ratio: Visual Warning
- Increase Inspiratory Flow: Visual Warning
- Reverse Battery Connection: Continuous Audible
- Low Internal Battery: Visual/Continuous Audible
- Low External Battery: Visual/Continuous Audible
- Power Failure: Continuous Audible
- Unit Malfunction: Intermittent Audible
- Power Source Change: Continuous Audible
- Oxygen: Continuous Audible
